MYIR Launches Renesas RZ/T2H-based SoM for High-Performance Industrial Real-Time Control

Shenzhen, China - April 21, 2026 - MYIR, a global provider of embedded System-on-Modules (SoMs) and solutions, today announced the launch of the MYC-YT2HX SoM, and its companion development board, the MYD-YT2HX. Built around the powerful Renesas RZ/T2H processor (R9A09G077M44GBG), this new solution is specifically engineered to meet the rigorous demands of high-performance industrial real-time control, multi-axis motor control, and industrial Ethernet applications.

Renesas RZ/T2H Processor Block Diagram

The MYC-YT2HX SoM integrates the Renesas RZ/T2H's unique heterogeneous architecture, which combines a Quad-Core Arm Cortex-A55 processor running up to 1.2GHz for complex application processing with a Dual-Core Arm Cortex-R52 processor running up to 1.0GHz for deterministic, low-latency real-time control. This single-chip solution enables the precise control of up to 9 axes of motors, making it ideal for advanced industrial robots, motion controllers, PLCs, and multi-axis servo drives.

Despite its powerful capabilities, the MYC-YT2HX maintains a compact footprint of just 50mm x 52mm, and features a rugged 336-pin (192-pin LCC + 144-pin LGA) expansion interface. MYIR has equipped the module with a robust hardware configuration designed for demanding industrial environments:

Memory & Storage: 2GB LPDDR4, 8GB eMMC, 16MB QSPI NOR Flash

Connectivity: 4x MII Ethernet ports (supporting TSN and protocols like EtherCAT), 2x CAN-FD, 1x USB 2.0 HOST/OTG, 2x PCIe Gen3 channels, and an extensive array of UART, I2C, and SPI interfaces.

Motor Control & I/O: 9-channel PWM MTU, 56-channel PWM GPT, 14-channel ADC, and a 30-channel Delta-Sigma Interface (DSMIF).

Display: 24-bit RGB interface supporting WXGA (1280x800) @ 60fps.

Industrial Grade: Supports a wide operating temperature range of -40°C to +85°C.

MYC-YT2HX System-On-Module Top-view and Bottom-view

Accelerate Development with the MYD-YT2HX Development Board

To facilitate rapid prototyping, MYIR also launched the MYD-YT2HX Development Board. This board features the MYC-YT2HX SoM pre-mounted on a dedicated carrier board that unlocks the full potential of the RZ/T2H processor. Key carrier board features include four 10/100 Mbps Ethernet ports, industrial RS232/RS485 and CAN-FD interfaces via Phoenix connectors, a Micro SD card slot, a 24-bit RGB display interface (compatible with MYIR's MY-TFT070RV2 7-inch LCD module), 12-channel ADC inputs, and two 3x32-pin expansion connectors for flexible functional expansion.

The development kit ships with a Linux 5.10 operating system, complete software packages including U-boot, kernel source, peripheral drivers, and comprehensive documentation. The bundle includes a USB Type A-to-C cable, a 12V/2A power adapter, Phoenix connectors, and a Quick Start Guide, providing an out-of-the-box development experience.

The MYC-YT2HX SoM (Part No. MYC-YT2H44-8E2D-120-I) is available for order now. MYIR also provides comprehensive customization and OEM services, allowing customers to modify circuit designs and software configurations to meet specific project requirements.

For more information, pricing, or to request samples, please visit the official product page:
https://en.myir.cn/RZT2H/168.html
